Advanced Deployment Patterns

🚀 Advanced Kubernetes Deployment Patterns

The Traffic Controller Story

Imagine you run the world’s busiest airport. Planes (your apps) need to land safely, passengers (users) need smooth connections, and you can’t shut down the runway to fix things. That’s Kubernetes deployment patterns!

You’re the Air Traffic Controller. Your job? Get new planes in the sky, retire old ones, and never crash anything.

🕸️ Service Mesh Concepts

What is a Service Mesh?

Think of your airport with hundreds of planes talking to each other. Now imagine every plane has a co-pilot robot that handles all the radio chatter automatically.

That’s a service mesh!

Without Service Mesh:
Plane A ----calls----> Plane B (manually)

With Service Mesh:
Plane A -> [Robot Co-pilot] -> [Robot Co-pilot] -> Plane B
           (handles routing, security, retries)

Why Do We Need It?

Your apps are like planes. They need to:

• Find each other (service discovery)
• Talk securely (encryption)
• Retry if busy (resilience)
• Report problems (observability)

The service mesh handles ALL of this. Your app just flies!

Real Example: Istio

# Istio injects a sidecar proxy automatically
apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
spec:
  template:
    metadata:
      labels:
        app: my-app
    # Istio adds envoy proxy here!

Key Players:

• Istio - Most popular, feature-rich
• Linkerd - Lightweight, simple
• Consul Connect - HashiCorp’s solution

🚦 Traffic Management Patterns

The Traffic Light System

Your airport has traffic lights for planes. You control:

• Who goes where (routing)
• How fast (rate limiting)
• What happens on problems (retries, timeouts)

Pattern 1: Weighted Routing

Send some passengers to the new terminal, most to the old one.

apiVersion: networking.istio.io/v1
kind: VirtualService
metadata:
  name: my-app
spec:
  hosts:
  - my-app
  http:
  - route:
    - destination:
        host: my-app
        subset: v1
      weight: 90    # 90% traffic
    - destination:
        host: my-app
        subset: v2
      weight: 10    # 10% traffic

Pattern 2: Header-Based Routing

VIP passengers get the new terminal!

http:
- match:
  - headers:
      user-type:
        exact: "premium"
  route:
  - destination:
      host: my-app
      subset: v2    # Premium gets v2

Pattern 3: Circuit Breaker

If a terminal is overwhelmed, stop sending people there!

apiVersion: networking.istio.io/v1
kind: DestinationRule
metadata:
  name: my-app
spec:
  host: my-app
  trafficPolicy:
    outlierDetection:
      consecutive5xxErrors: 5
      interval: 30s
      baseEjectionTime: 60s

🐤 Canary Deployments

The Canary in the Coal Mine

Miners used canaries to detect danger. If the bird stopped singing, get out!

Canary deployment: Send a tiny bit of traffic to the new version. If it fails, only a few users are affected.

graph TD
    A["Users 100%"] --> B{Load Balancer}
    B -->|95%| C["Version 1 - Stable"]
    B -->|5%| D["Version 2 - Canary"]
    D --> E{Healthy?}
    E -->|Yes| F["Increase to 25%"]
    E -->|No| G["Rollback to v1"]

Canary in Action

Step 1: Deploy canary with 5% traffic

weight: 95  # v1
weight: 5   # v2 (canary)

Step 2: Watch metrics (errors, latency)

Step 3: If good, increase traffic gradually

weight: 75  # v1
weight: 25  # v2

Step 4: Eventually, 100% to v2

🔵🟢 Blue-Green Deployments

Two Terminals, One Switch

You have two identical terminals:

• Blue = Currently serving passengers
• Green = New version, waiting

When Green is ready, flip the switch! All passengers go to Green.

graph TD
    A["DNS/Load Balancer"] --> B{Switch}
    B -->|Active| C["🔵 Blue - v1"]
    B -->|Standby| D["🟢 Green - v2"]

    E["After Testing"] --> F{Flip Switch}
    F --> G["🟢 Green - Now Active"]
    F --> H["🔵 Blue - Now Standby"]

Blue-Green Example

Step 1: Both versions running

# Blue is live
kubectl get svc my-app
# Points to: blue-deployment

Step 2: Test Green thoroughly

Step 3: Flip the switch!

kubectl patch svc my-app \
  -p '{"spec":{"selector":{"version":"green"}}}'

Step 4: If problems, flip back instantly!

Canary vs Blue-Green

📦 GitOps Fundamentals

The Single Source of Truth

Imagine your airport’s control tower has ONE master flight plan. Every controller reads from it. No one makes changes without updating the plan.

That’s GitOps!

Git = Your master flight plan Ops = Automatic deployment

graph TD
    A["Developer"] -->|1. Push Code| B["Git Repository"]
    B -->|2. Trigger| C["CI Pipeline"]
    C -->|3. Build Image| D["Container Registry"]
    B -->|4. Detect Change| E["GitOps Operator"]
    E -->|5. Apply| F["Kubernetes Cluster"]

The Four Principles

1. Declarative - Describe WHAT you want, not HOW
2. Versioned - Everything in Git
3. Automated - Changes applied automatically
4. Self-healing - Drift detected and corrected

Why GitOps Rocks

Traditional:
Developer -> SSH -> Server -> Hope it works

GitOps:
Developer -> Git Push -> Automatic Magic -> Verified State

• Audit trail - Git history shows everything
• Rollback - git revert fixes disasters
• Security - No direct cluster access needed

🦑 ArgoCD Basics

Your Automated Pilot

ArgoCD is like an autopilot that:

1. Watches your Git repo
2. Compares it to your cluster
3. Makes them match automatically

Installing ArgoCD

# Create namespace
kubectl create namespace argocd

# Install ArgoCD
kubectl apply -n argocd -f \
  https://raw.githubusercontent.com/argoproj/\
  argo-cd/stable/manifests/install.yaml

# Get admin password
kubectl -n argocd get secret \
  argocd-initial-admin-secret \
  -o jsonpath="{.data.password}" | base64 -d

ArgoCD Architecture

graph TD
    A["Git Repository"] --> B["ArgoCD Server"]
    B --> C["Application Controller"]
    C --> D{Compare}
    D -->|Match| E["✅ Synced"]
    D -->|Differ| F["⚠️ Out of Sync"]
    F --> G["Auto-Sync or Manual"]
    G --> H["Apply to Cluster"]

Key Components

• API Server - Web UI and CLI access
• Repo Server - Fetches and processes Git
• Application Controller - Watches and syncs

🔄 ArgoCD Applications Sync

Your Flight Plan Executor

An ArgoCD Application tells ArgoCD:

• WHERE to get the config (Git repo)
• WHAT to deploy (path in repo)
• WHERE to deploy (Kubernetes cluster)

Creating an Application

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-app
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://github.com/my/repo
    targetRevision: main
    path: kubernetes/my-app
  destination:
    server: https://kubernetes.default.svc
    namespace: production
  syncPolicy:
    automated:
      prune: true      # Delete removed resources
      selfHeal: true   # Fix drift automatically

Sync Strategies

Manual Sync:

argocd app sync my-app

Automatic Sync:

syncPolicy:
  automated:
    prune: true
    selfHeal: true

Sync Status Icons

🌳 App-of-Apps Pattern

The Master Flight Plan

One Application that manages all other Applications!

Instead of creating 50 apps manually, create ONE app that points to a folder containing 50 app definitions.

graph TD
    A["Root Application"] --> B["apps/ folder in Git"]
    B --> C["app-1.yaml"]
    B --> D["app-2.yaml"]
    B --> E["app-3.yaml"]
    B --> F["app-n.yaml"]
    C --> G["Deploys App 1"]
    D --> H["Deploys App 2"]
    E --> I["Deploys App 3"]

The Root App

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: root-app
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://github.com/my/repo
    path: argocd-apps  # Folder with app YAMLs
    targetRevision: main
  destination:
    server: https://kubernetes.default.svc
    namespace: argocd
  syncPolicy:
    automated:
      selfHeal: true

Child App Example

# argocd-apps/frontend.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: frontend
  namespace: argocd
spec:
  source:
    repoURL: https://github.com/my/repo
    path: apps/frontend
  destination:
    server: https://kubernetes.default.svc
    namespace: frontend

Benefits

• Single source - One repo rules all
• Scalable - Add apps by adding files
• Consistent - Same pattern everywhere

⏱️ Zero-Downtime Deployment

Never Close the Airport

Your passengers (users) should NEVER see “Airport Closed.” Even during upgrades!

Strategy 1: Rolling Update (Default)

Replace pods one by one, never all at once.

apiVersion: apps/v1
kind: Deployment
spec:
  replicas: 4
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxUnavailable: 1   # Only 1 pod down
      maxSurge: 1         # Only 1 extra pod

graph LR
    A["v1 v1 v1 v1"] --> B["v1 v1 v1 v2"]
    B --> C["v1 v1 v2 v2"]
    C --> D["v1 v2 v2 v2"]
    D --> E["v2 v2 v2 v2"]

Strategy 2: Readiness Probes

Don’t send traffic until the new pod is ready!

readinessProbe:
  httpGet:
    path: /health
    port: 8080
  initialDelaySeconds: 5
  periodSeconds: 10

Strategy 3: Graceful Shutdown

Let existing requests finish before killing the pod.

spec:
  terminationGracePeriodSeconds: 30
  containers:
  - name: app
    lifecycle:
      preStop:
        exec:
          command: ["/bin/sh", "-c", "sleep 10"]

The Zero-Downtime Checklist

✅ Rolling updates with proper maxUnavailable ✅ Readiness probes - only serve when ready ✅ Graceful shutdown - finish existing requests ✅ Pod disruption budgets - protect availability ✅ Health checks - detect problems early

apiVersion: policy/v1
kind: PodDisruptionBudget
metadata:
  name: my-app-pdb
spec:
  minAvailable: 2   # Always keep 2 pods running
  selector:
    matchLabels:
      app: my-app

🎯 Putting It All Together

graph TD
    A["Developer Pushes to Git"] --> B["ArgoCD Detects Change"]
    B --> C["Service Mesh Routes Traffic"]
    C --> D{Deployment Strategy}
    D -->|Canary| E["5% to New Version"]
    D -->|Blue-Green| F["Switch All Traffic"]
    D -->|Rolling| G["Gradual Pod Replace"]
    E --> H{Metrics OK?}
    H -->|Yes| I["Increase Traffic"]
    H -->|No| J["Rollback"]
    F --> K["Instant Rollback Available"]
    G --> L["Zero Downtime Maintained"]

Your New Superpowers

🏆 You Did It!

You’re now an Air Traffic Controller for Kubernetes!

Remember:

• Service Mesh = Robot co-pilots for every pod
• Traffic Patterns = Smart routing rules
• Canary = Test with a few users first
• Blue-Green = Two versions, instant switch
• GitOps = Git is the boss
• ArgoCD = Your autopilot
• App-of-Apps = One app to rule them all
• Zero-Downtime = Never close the airport

Now go deploy with confidence! 🚀
