🌐 Kubernetes Cluster Networking: The City of Pods

Imagine your Kubernetes cluster is a magical city where tiny workers (Pods) live in different neighborhoods. They need roads, addresses, and traffic controllers to talk to each other. Let’s explore how this city works!

🏙️ The Big Picture: Cluster Network Basics

Think of a Kubernetes cluster like a city with many houses. Each house is a Pod, and every house needs:

1. An address (so mail carriers can find it)
2. Roads (so people can visit each other)
3. Traffic rules (so nobody crashes)

What Makes Cluster Networking Special?

In Kubernetes city, there’s a magical rule:

Every Pod can talk to every other Pod directly - no special permission needed!

It’s like having a city where every house has a direct road to every other house. No locked gates, no toll booths.

graph TD
    A["Pod A<br/>10.244.1.5"] -->|Direct Talk| B["Pod B<br/>10.244.2.8"]
    B -->|Direct Talk| C["Pod C<br/>10.244.3.2"]
    A -->|Direct Talk| C
    style A fill:#e3f2fd
    style B fill:#fff3e0
    style C fill:#e8f5e9

The Three Golden Rules

🔌 CNI Plugins: The Road Builders

What is CNI?

CNI stands for Container Network Interface. Think of it as the road construction company for our city.

When a new Pod (house) is built, someone needs to:

• Build a road to it ✅
• Give it an address ✅
• Connect it to the main highway ✅

That’s exactly what CNI plugins do!

How It Works (Simple Story)

1. 🏗️ Kubernetes says: “Build a new Pod!”
2. 📞 CNI plugin gets a call: “Hey, network setup needed!”
3. 🛤️ CNI builds the network “road” to the Pod
4. 🏷️ CNI gives the Pod its IP address
5. ✅ Pod is now connected to the city!

Popular CNI Plugins

Example: What Happens When Pod Starts

graph TD
    K["Kubelet"] -->|1. Create Pod| CNI["CNI Plugin"]
    CNI -->|2. Setup Network| N["Network Interface"]
    N -->|3. Assign IP| P["Pod Ready!<br/>IP: 10.244.1.5"]
    style K fill:#bbdefb
    style CNI fill:#c8e6c9
    style P fill:#fff9c4

📮 Pod and Service CIDR: The Address System

What is CIDR?

CIDR (say it: “cider”) is like a zip code system for our city. It tells us which addresses belong to which neighborhood.

Two Different Zip Code Zones

Kubernetes has two separate address neighborhoods:

Why Two Different Zones?

Think of it this way:

• Pods = Individual houses (they come and go)
• Services = Post offices (stable addresses that never change)

When you send a letter (request) to a Post Office (Service), the Post Office knows which houses (Pods) to deliver it to!

Real Numbers Example

Your Cluster Setup:
├── Pod CIDR: 10.244.0.0/16
│   ├── Node 1 Pods: 10.244.1.0/24 (256 addresses)
│   ├── Node 2 Pods: 10.244.2.0/24 (256 addresses)
│   └── Node 3 Pods: 10.244.3.0/24 (256 addresses)
│
└── Service CIDR: 10.96.0.0/12
    ├── kubernetes: 10.96.0.1
    ├── my-web-app: 10.96.45.123
    └── my-database: 10.96.89.67

The Magic: Why This Matters

graph TD
    subgraph Pod Network
        P1["Pod 1<br/>10.244.1.5"]
        P2["Pod 2<br/>10.244.2.8"]
    end
    subgraph Service Network
        S["Service<br/>10.96.0.100"]
    end
    U["User Request"] --> S
    S --> P1
    S --> P2
    style S fill:#e1bee7
    style P1 fill:#c8e6c9
    style P2 fill:#c8e6c9

🗣️ Pod-to-Pod Communication: How Pods Talk

The Simplest Thing in Kubernetes

Remember our golden rule? Every Pod can talk to every other Pod directly!

Three Scenarios

1️⃣ Same Node (Same Apartment Building)

Pods on the same node talk through a virtual bridge - like neighbors using the same elevator.

graph TD
    subgraph Node 1
        B["Bridge<br/>cbr0"]
        P1["Pod A<br/>10.244.1.5"] --- B
        P2["Pod B<br/>10.244.1.6"] --- B
    end
    P1 -->|Direct via bridge| P2
    style B fill:#ffcdd2
    style P1 fill:#c8e6c9
    style P2 fill:#bbdefb

Example: Pod A (10.244.1.5) calls Pod B (10.244.1.6)

• Traffic goes: Pod A → Bridge → Pod B
• Super fast! Never leaves the node.

2️⃣ Different Nodes (Different Buildings)

Pods on different nodes need the overlay network - like cars driving between buildings.

graph LR
    subgraph Node 1
        P1["Pod A<br/>10.244.1.5"]
    end
    subgraph Node 2
        P2["Pod C<br/>10.244.2.8"]
    end
    P1 -->|Overlay Network| P2
    style P1 fill:#c8e6c9
    style P2 fill:#bbdefb

Example: Pod A (Node 1) calls Pod C (Node 2)

• Traffic is encapsulated (put in an envelope)
• Sent across the physical network
• Unwrapped at destination node
• Delivered to Pod C

3️⃣ Through a Service (Using the Post Office)

Most real apps use Services for stable addressing.

Web Pod → Service IP → Database Pod
         (10.96.0.50)

Quick Comparison

🚦 kube-proxy Modes: The Traffic Controller

What is kube-proxy?

kube-proxy is like a traffic controller that runs on every node. Its job:

When traffic arrives for a Service, direct it to the right Pod!

Three Modes: How Traffic Gets Directed

Mode 1: iptables (The Rule Book) 📖

Default mode in most clusters

Think of it as a giant rulebook that says:

• “If traffic goes to 10.96.0.50, send it to Pod at 10.244.1.5”

graph LR
    T["Traffic"] --> IP["iptables Rules"]
    IP --> P1["Pod 1"]
    IP --> P2["Pod 2"]
    IP --> P3["Pod 3"]
    style IP fill:#ffecb3

Mode 2: IPVS (The Smart Router) 🧠

Better for large clusters

IPVS is like having a professional traffic management system instead of just rules.

graph LR
    T["Traffic"] --> IPVS["IPVS<br/>Load Balancer"]
    IPVS --> P1["Pod 1"]
    IPVS --> P2["Pod 2"]
    IPVS --> P3["Pod 3"]
    style IPVS fill:#c8e6c9

Load Balancing Options in IPVS:

• Round-robin (take turns)
• Least connections (send to least busy)
• Source hashing (same user → same pod)

Mode 3: kernelspace/nftables (The New Kid) 🆕

Newer, modern approach

Uses modern Linux networking features.

Quick Mode Comparison

How to Check Your Mode

# See what mode kube-proxy uses
kubectl get configmap \
  kube-proxy -n kube-system \
  -o yaml | grep mode

🎯 Putting It All Together

Let’s trace a real request through the entire system!

Story: Web App Calls Database

graph TD
    U["User"] -->|1. Request| S["Web Service<br/>10.96.0.50"]
    S -->|2. kube-proxy routes| WP["Web Pod<br/>10.244.1.5"]
    WP -->|3. Calls db-service| DS["DB Service<br/>10.96.0.100"]
    DS -->|4. kube-proxy routes| DP["DB Pod<br/>10.244.2.8"]
    DP -->|5. Response| WP
    WP -->|6. Response| U

    style S fill:#e1bee7
    style DS fill:#e1bee7
    style WP fill:#c8e6c9
    style DP fill:#bbdefb

What Happened:

1. User sends request to Web Service (10.96.0.50)
2. kube-proxy on the node routes to Web Pod (10.244.1.5)
3. Web Pod needs data, calls DB Service (10.96.0.100)
4. kube-proxy routes to DB Pod (10.244.2.8) - maybe different node!
5. DB Pod sends data back
6. Response returns to user

The Key Players Summary

🏆 You Made It!

You now understand how the Kubernetes networking city works:

• 🛤️ CNI plugins build the roads and assign addresses
• 📮 Pod & Service CIDR keep addresses organized in zones
• 🗣️ Pods talk directly to each other (same or different nodes)
• 🚦 kube-proxy directs traffic from Services to the right Pods

Remember: Every Pod is a citizen with equal rights to talk to any other Pod. Services are like post offices with stable addresses. And kube-proxy is the traffic controller making sure everyone finds their way!

Happy networking in your Kubernetes city! 🎉
