Network Policies

🛡️ Kubernetes Network Policies: The Security Guards of Your Cluster

The Story: Your Cluster is a Gated Community

Imagine your Kubernetes cluster as a big apartment building. Each apartment (Pod) has different people (containers) living inside. Now, without any rules, anyone could knock on any door and walk into any apartment! 😱

That’s where Network Policies come in. They’re like security guards at each apartment door, checking IDs and deciding who can come in and who can go out.

🏠 What Are Network Policies?

Think of Network Policies as “No Entry” signs with a guest list.

By default, Kubernetes is like a friendly neighborhood where everyone can talk to everyone. But sometimes, you need rules:

• 🚫 “Only my friends from Building A can visit”
• 🚫 “I can only go to the grocery store (port 80), not the casino (port 443)”
• 🚫 “Nobody comes in unless they’re on my list”

Simple Definition:

A Network Policy is a set of rules that controls how Pods communicate with each other and with the outside world.

Real-World Example

Your “payment” Pod should only talk to:

• ✅ The “database” Pod
• ✅ The “logging” Pod
• ❌ NOT the “games” Pod
• ❌ NOT random internet traffic

📜 Network Policy Rules: The Guest List

Every Network Policy has rules that answer three questions:

The Three Types of Rules

graph TD
    A["Network Policy"] --> B["Ingress Rules"]
    A --> C["Egress Rules"]
    B --> D["Who can come IN?"]
    C --> E["Where can I go OUT?"]

🚪 Ingress = Incoming Traffic

“Who is allowed to knock on MY door?”

ingress:
  - from:
      - podSelector:
          matchLabels:
            role: frontend
    ports:
      - port: 80

Translation: “Only Pods labeled role: frontend can visit me, and only through port 80.”

🚀 Egress = Outgoing Traffic

“Where am I allowed to go?”

egress:
  - to:
      - podSelector:
          matchLabels:
            role: database
    ports:
      - port: 5432

Translation: “I can only visit Pods labeled role: database on port 5432.”

🎯 Network Policy Selectors: Finding the Right Pods

Selectors are like name tags that help the security guard identify who’s who.

Three Types of Selectors

graph TD
    A["Selectors"] --> B["podSelector"]
    A --> C["namespaceSelector"]
    A --> D["ipBlock"]
    B --> E["Match Pods by labels"]
    C --> F["Match entire namespaces"]
    D --> G["Match IP addresses"]

1️⃣ Pod Selector

“Find Pods wearing THIS name tag”

podSelector:
  matchLabels:
    app: web
    tier: frontend

Translation: “Only Pods with BOTH labels app: web AND tier: frontend”

2️⃣ Namespace Selector

“Find everyone in THIS building”

namespaceSelector:
  matchLabels:
    environment: production

Translation: “Allow traffic from ANY Pod in namespaces labeled environment: production”

3️⃣ IP Block Selector

“Allow visitors from THESE addresses”

ipBlock:
  cidr: 192.168.1.0/24
  except:
    - 192.168.1.100/32

Translation: “Allow traffic from 192.168.1.0 to 192.168.1.255, EXCEPT 192.168.1.100”

🔀 Combining Selectors

You can mix and match! Here’s a powerful combo:

ingress:
  - from:
      - namespaceSelector:
          matchLabels:
            team: payments
        podSelector:
          matchLabels:
            role: api

Translation: “Only allow Pods labeled role: api that are ALSO in namespaces labeled team: payments”

🚧 Default Deny Policies: Lock Everything Down First!

This is the golden rule of network security:

“Deny everything by default, then allow only what’s needed.”

Why Default Deny?

Imagine leaving all apartment doors wide open and then trying to remember which ones to lock.

Instead:

1. 🔐 Lock ALL doors first
2. 🔑 Give keys only to trusted visitors

Default Deny All Ingress

“Nobody comes in unless I say so!”

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: deny-all-ingress
  namespace: production
spec:
  podSelector: {}
  policyTypes:
    - Ingress

What’s happening here?

• podSelector: {} = Select ALL Pods in this namespace
• policyTypes: [Ingress] = Apply to incoming traffic
• No ingress rules = No incoming traffic allowed!

Default Deny All Egress

“Nobody goes out unless I say so!”

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: deny-all-egress
  namespace: production
spec:
  podSelector: {}
  policyTypes:
    - Egress

Default Deny BOTH (Ultimate Lockdown)

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: deny-all
  namespace: production
spec:
  podSelector: {}
  policyTypes:
    - Ingress
    - Egress

Warning! 🚨 After applying this, your Pods can’t talk to ANYONE—not even DNS! You’ll need to add specific allow rules.

🎨 Putting It All Together: A Complete Example

Here’s a real-world scenario for a three-tier app:

graph TD
    Internet((Internet)) --> FE["Frontend Pods"]
    FE --> API["API Pods"]
    API --> DB["#40;Database Pods#41;"]

    style FE fill:#4CAF50
    style API fill:#2196F3
    style DB fill:#9C27B0

Step 1: Default Deny in Production

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: default-deny-all
  namespace: production
spec:
  podSelector: {}
  policyTypes:
    - Ingress
    - Egress

Step 2: Allow Frontend to Talk to API

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-frontend-to-api
  namespace: production
spec:
  podSelector:
    matchLabels:
      tier: api
  policyTypes:
    - Ingress
  ingress:
    - from:
        - podSelector:
            matchLabels:
              tier: frontend
      ports:
        - port: 8080

Step 3: Allow API to Talk to Database

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-api-to-db
  namespace: production
spec:
  podSelector:
    matchLabels:
      tier: database
  policyTypes:
    - Ingress
  ingress:
    - from:
        - podSelector:
            matchLabels:
              tier: api
      ports:
        - port: 5432

🧠 Key Takeaways

🎉 You Did It!

You now understand how to:

• ✅ Create rules for who can talk to your Pods
• ✅ Use selectors to target specific Pods
• ✅ Lock down your cluster with default deny policies

Remember: Network Policies are like good security guards—they only let the right people in and keep the troublemakers out! 🛡️
